ESC enclosure v1.2B

ESC Enclosure v1.2B – Efficient Heat Dissipation for Optimal Performance

Compatible with ESCs such as:

• Spintend uBox

• 2× Trampa VESC 6

• Focbox Unity / BKB Xenith

• Lacroix Stormcore 60D / 100D

• MakerX DV6, GO-FOC D75, D100, DV4S, DV6S, D100S

Construction:

• Top cover, bottom plate, and truck mounting plate: 7075 aluminum (aircraft grade)

• Middle section: Polyethylene, available in 30 mm or 40 mm height variants

Designed to provide efficient heat dissipation, this enclosure helps maintain optimal ESC performance, even under demanding riding conditions.

Specifications:

• Model: ESC enclosure v1.2B

• Materials: Aluminum Alloy 7075 + Polyethylene

• Color options: Black / Silver / Orange Gold

• Internal dimensions: 159 mm (W) × 119 mm (L) × 30 mm or 40 mm (H)

Important Notes:

• The switch is not included.

• The bottom plate is delivered without pre-drilled ESC mounting holes, as hole patterns vary between ESC models. The user should drill holes to match their specific ESC.

• Price is for one ESC enclosure.

Additional Option:

• On request, the enclosure can be supplied with a 40 mm middle section made from PETG (Polyethylene Terephthalate Glycol) manufactured using 3D printing technology.

• The price remains unchanged for this option.
